Diffused 33-Segment Pixel Matrix
a.k.a. 'D33SPM' {by dpla}

7- to 33-segment progression
(bitmap-only step-by-step)***



FONT MAPPING =

Abbreviations:
. 'S' Segment (#)
. 'L' Layer (I2O [Groups: 1/23/45/67])
. 'C' Character (ANSI)*
. 'U' Unicode (00+HEX)
. 'P' Position (Clockwise) [Matrix V1]**
. 'I' In/Inner
. 'O' Out/Outer


I to O table:

.S L C .U P..
==-=-=-==-===
00 1 0 30 Mdl
-- - - -- ---
01 2 1 31 N
02 2 2 32  E
03 2 3 33 S
04 2 4 34  W
-- - - -- ---
05 3 5 35 NE
06 3 6 36 SE
07 3 7 37 SW
08 3 8 38 NW
-- - - -- ---
09 4 9 39 NE
10 4 A 41 SE
11 4 B 42 SW
12 4 C 43 NW
-- - - -- ---
13 5 D 44 N
14 5 E 45  E
15 5 F 46 S
16 5 G 47  W
-- - - -- ---
17 6 H 48 NNE
18 6 I 49 NEE
19 6 J 4A SEE
20 6 K 4B SSE
21 6 L 4C SSW
22 6 M 4D SWW
23 6 N 4E NWW
24 6 O 4F NNW
-- - - -- ---
25 7 P 50 NNE
26 7 Q 51 NEE
27 7 R 52 SEE
28 7 S 53 SSE
29 7 T 54 SSW
30 7 U 55 SWW
31 7 V 56 NWW
32 7 W 57 NNW



NOTES =

* So that the FULL MATRIX can be revealed
 by enabling all the segments (33 layers)
 via "0123456789ABCDEFGHIJKLMNOPQRSTUVW"
(or any distribution of this full string).

**
Now you may 'fontstruct' my 25TH VERSION…
(the "MARS:BENZ" test showcases this one).

***
The expected final & plain VECTOR DESIGNS
could simply begin with rotating squares…
Even in this early and geometric step #0,
all the 33 segment areas would be similar.

33?!
1 BIT too many… try removing S00 yourself
(or merge by adding a 'separating value').

Use the glyph SPACING as usual in x and y
(even by kerning the variable width font).

I started drawing many V1 GLYPHS on April
(+ several ANIMATIONS for matrix testing).

The inherited 7-SEGMENT matrix is a LIMIT
